	High speed
	USC-F5-k30
	Nanoworld
Coating: Gold Reflex Coating
Force Const / Res. Freq:
30 N/m / 5000 kHz

	Contact,Biological
	qp-CONT-10
	Nanosensors
Coating: Particl Au
Force Const / Res. Freq:
0.1 N/m / 30 kHz

	conductive/EFM
	AIOE
	Budgetsensors
Coating: Cr/Pt
Force Const / Res. Freq:
0.2 N/m / 15 kHz 2.7 N/m / 80 kHz 7.4 N/m / 150 kHz 40 N/m / 320 kHz

	Tapping/Contact
	HQ:XSC11/Al BS
	MikroMasch
Coating: Aluminum
Force Const / Res. Freq:
0.2 N/m / 15 kHz 2.7 N/m / 80 kHz 7 N/m / 155 kHz 42 N/m / 350 kHz

Minusk

BM-10 Bench Top Vibration Isolation Platform

Weight: Approximately 35 lb (16 kg)
Dimensions: 12.2” W x 12.2” D x 4.6” H (310mm W x 310mm D x 117mm H)
Approximate payload weight range:
Model	Payload Range*	Price**
10BM-10	0 - 10 lb (0 - 4.5 kg)	$2,656.50
25BM-10	10 - 30 lb (4.5 - 14 kg)	$2,714.25
50BM-10	30 - 55 lb (14 - 25 kg)	$2,772
75BM-10	50 - 80 lb (22.5 -36 kg)	$2,829.75
100BM-10	75 - 110 lb (34 - 50 kg)	$2,887.50
Performance
Horizontal frequencies are weight dependent. Horizontal frequency of 1.5 Hz is achieved at the upper limit of the payload range. At the lower limits of the payload range the horizontal frequency is approximately 2.5 Hz. Vertical frequency is tunable to 0.5 Hz throughout the payload range.
Simple Set-Up and Adjustment

BM-10 Bench Top | Small Vibration Isolators

The BM-10 bench top platform offers 10-100 times better performance than a full size air table in a package only 4.6 inches tall and 12 inches wide and deep. It also does this without any air or electricity!

This vibration isolation platform is extremely easy to use and offers extreme performance. It offers a 1.5Hz horizontal natural frequency and our signature 0.5 Hz vertical natural frequency. There are only two adjustments. The BM-10 is perfect for new generations of small SPM's that require the highest performance in a very compact system.

This is the thinnest, smallest footprint, most portable, and most user-friendly isolator ever offered that is capable of delivering this level of performance.They can also be made cleanroom and vacuum capatible.
